Name: 8-Channel PWM or Servo FeatherWing Add-on For All Feather Boards
Brand: Adafruit

ADA2928 · AdafruitActive

Adafruit product #2928.

Part number	ADA2928
Manufacturer	Adafruit
Category	Motor Drivers & Controllers › Servo & PWM Controllers
Pins	84
Channels	8

8-Channel PWM or Servo FeatherWing Add-on For All Feather Boards pinout

Pin	Name	Type
1	VBAT	power
2	EN	bidirectional
3	USB	power
4	N	bidirectional
5	M	bidirectional
6	L	bidirectional
7	K	bidirectional
8	J	bidirectional
9	I	bidirectional
10	H	bidirectional
11	SCL	bidirectional
12	SDA	bidirectional
13	PWRIN	bidirectional
14	GND	ground
15	VBAT	power
16	EN	bidirectional
17	USB	power
18	N	bidirectional
19	M	bidirectional
20	L	bidirectional
21	K	bidirectional
22	J	bidirectional
23	I	bidirectional
24	H	bidirectional
25	SCL	bidirectional
26	SDA	bidirectional
27	GND	ground
28	V+	power
29	PWM_0	bidirectional
30	V+	power
31	PWM_7	bidirectional
32	V+	power
33	GND	ground
34	GND	ground
35	V+	power
36	PWM_1	bidirectional
37	PWM_6	bidirectional
38	V+	power
39	GND	ground
40	GND	ground
41	GND	ground
42	V+	power
43	PWM_2	bidirectional
44	PWM_5	bidirectional
45	V+	power
46	GND	ground
47	GND	ground
48	V+	power
49	PWM_3	bidirectional
50	PWM_4	bidirectional
51	V+	power
52	GND	ground
53	RESET	bidirectional
54	+3.3V	power
55	AREF	bidirectional
56	GND	ground
57	A	bidirectional
58	B	bidirectional
59	C	bidirectional
60	D	bidirectional
61	E	bidirectional
62	F	bidirectional
63	SCK	bidirectional
64	MOSI	bidirectional
65	MISO	bidirectional
66	RX	bidirectional
67	TX	bidirectional
68	G	bidirectional
69	RESET	bidirectional
70	+3.3V	power
71	AREF	bidirectional
72	GND	ground
73	A	bidirectional
