ADA6357 · AdafruitActive
Adafruit product #6357 — built on AS5600.
| Part number | ADA6357 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › Magnetic & Hall |
| Pins | 6 |
Adafruit AS5600 Magnetic Angle Sensor pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VCC | power | |
| 2 | 3.3V | power | |
| 3 | GND | ground | |
| 4 | SCL | bidirectional | |
| 5 | SDA | bidirectional | |
| 6 | PWMOUT | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit AS5600 Magnetic Angle Sensor (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
