ADA2923 · AdafruitActive
Adafruit product #2923.
| Part number | ADA2923 |
|---|---|
| Manufacturer | Adafruit |
| Category | Relays › Relay Modules |
| Pins | 61 |
Adafruit Latching Mini Relay FeatherWing pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VBAT | power | |
| 2 | EN | bidirectional | |
| 3 | USB | power | |
| 4 | N | bidirectional | |
| 5 | M | bidirectional | |
| 6 | L | bidirectional | |
| 7 | K | bidirectional | |
| 8 | J | bidirectional | |
| 9 | I | bidirectional | |
| 10 | H | bidirectional | |
| 11 | SCL | bidirectional | |
| 12 | SDA | bidirectional | |
| 13 | VBAT | power | |
| 14 | EN | bidirectional | |
| 15 | USB | power | |
| 16 | N | bidirectional | |
| 17 | M | bidirectional | |
| 18 | L | bidirectional | |
| 19 | K | bidirectional | |
| 20 | J | bidirectional | |
| 21 | I | bidirectional | |
| 22 | H | bidirectional | |
| 23 | SCL | bidirectional | |
| 24 | SDA | bidirectional | |
| 25 | NO | bidirectional | |
| 26 | UNSET | bidirectional | |
| 27 | COM | bidirectional | |
| 28 | SET | bidirectional | |
| 29 | NC | bidirectional | |
| 30 | RESET | bidirectional | |
| 31 | 3.3V | power | |
| 32 | AREF | bidirectional | |
| 33 | GND | ground | |
| 34 | A | bidirectional | |
| 35 | B | bidirectional | |
| 36 | C | bidirectional | |
| 37 | D | bidirectional | |
| 38 | E | bidirectional | |
| 39 | F | bidirectional | |
| 40 | SCK | bidirectional | |
| 41 | MOSI | bidirectional | |
| 42 | MISO | bidirectional | |
| 43 | RX | bidirectional | |
| 44 | TX | bidirectional | |
| 45 | G | bidirectional | |
| 46 | RESET | bidirectional | |
| 47 | 3.3V | power | |
| 48 | AREF | bidirectional | |
| 49 | GND | ground | |
| 50 | A | bidirectional | |
| 51 | B | bidirectional | |
| 52 | C | bidirectional | |
| 53 | D | bidirectional | |
| 54 | E | bidirectional | |
| 55 | F | bidirectional | |
| 56 | SCK | bidirectional | |
| 57 | MOSI | bidirectional | |
| 58 | MISO | bidirectional | |
| 59 | RX | bidirectional | |
| 60 | TX | bidirectional | |
| 61 | G | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit Latching Mini Relay FeatherWing (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Datasheet
