ADA5217 · AdafruitActive
Adafruit product #5217 — built on NRF52840.
| Part number | ADA5217 |
|---|---|
| Manufacturer | Adafruit |
| Category | Development Boards › nRF52 / nRF54 Boards |
| Pins | 3 |
| Frequency | 2.4 GHz |
Adafruit LED Glasses Driver - nRF52840 Sensor Board pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | RESET | bidirectional | |
| 2 | SWDIO | bidirectional | |
| 3 | SWCLK | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit EyeLights LED Glasses Driver (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Where to buy
Stock and prices from the suppliers, checked 2026-10-08; excluding tax and shipping.
