ADA6354 · AdafruitActive
Adafruit product #6354 — built on TPS61169.
| Part number | ADA6354 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › Current & Voltage |
| Pins | 9 |
| Current | 400 mA |
| Voltage (max) | 40 V |
Adafruit TPS61169 Constant Current Boost Converter for LEDs pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | GND | ground | |
| 2 | LEDK | bidirectional | |
| 3 | VIN | power | |
| 4 | +24V | bidirectional | |
| 5 | VIN | power | |
| 6 | GND | ground | |
| 7 | PWM | bidirectional | |
| 8 | +24V | bidirectional | |
| 9 | LEDK | bidirectional |
Schematic symbol and footprint
Schematic symbol
Footprint: Adafruit TPS61169 Constant Current Boost Converter LED Driver (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
