ADA5396 · AdafruitActive
Adafruit product #5396 — built on VL53L4CD.
| Part number | ADA5396 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › Distance, ToF & Proximity |
| Pins | 6 |
Adafruit VL53L4CD Time of Flight Distance Sensor - ~1 to 1300mm pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VCC | power | |
| 2 | GND | ground | |
| 3 | SCL | bidirectional | |
| 4 | SDA | bidirectional | |
| 5 | GPIO | bidirectional | |
| 6 | XSHUT | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit VL53L4CD (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
