Name: Adalogger FeatherWing - RTC + SD Add-on For All Feather Boards
Brand: Adafruit

ADA2922 · AdafruitActive

Adafruit product #2922.

Part number	ADA2922
Manufacturer	Adafruit
Category	Interface & Expansion › RTC & Timing
Pins	58

Adalogger FeatherWing - RTC + SD Add-on For All Feather Boards pinout

Pin	Name	Type
1	VBAT	power
2	EN	bidirectional
3	USB	power
4	N	bidirectional
5	M	bidirectional
6	L	bidirectional
7	CS	bidirectional
8	J	bidirectional
9	I	bidirectional
10	H	bidirectional
11	SCL	bidirectional
12	SDA	bidirectional
13	EN	bidirectional
14	USB	power
15	N	bidirectional
16	M	bidirectional
17	L	bidirectional
18	CS	bidirectional
19	J	bidirectional
20	I	bidirectional
21	H	bidirectional
22	SCL	bidirectional
23	SDA	bidirectional
24	VBAT	power
25	SD_CS	bidirectional
26	INT1	bidirectional
27	RESET	bidirectional
28	+3V3	power
29	AREF	bidirectional
30	GND	ground
31	A	bidirectional
32	B	bidirectional
33	C	bidirectional
34	D	bidirectional
35	E	bidirectional
36	F	bidirectional
37	SCK	bidirectional
38	MOSI	bidirectional
39	MISO	bidirectional
40	RX	bidirectional
41	TX	bidirectional
42	G	bidirectional
43	RESET	bidirectional
44	+3V3	power
45	AREF	bidirectional
46	GND	ground
47	A	bidirectional
48	B	bidirectional
49	C	bidirectional
50	D	bidirectional
51	E	bidirectional
52	F	bidirectional
53	SCK	bidirectional
54	MOSI	bidirectional
55	MISO	bidirectional
56	RX	bidirectional
57	TX	bidirectional
58	G	bidirectional
