ADA1713 · Adafruit
Adafruit product #1713 — built on MAX9814.
| Part number | ADA1713 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › Microphones & Sound |
| Pins | 5 |
Electret Microphone Amplifier - MAX9814 with Auto Gain Control pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | A/R | bidirectional | |
| 2 | OUTPUT | bidirectional | |
| 3 | GAIN | bidirectional | |
| 4 | VDD | power | |
| 5 | GND | ground |
Schematic symbol and footprint
Footprint: Adafruit MAX9814 Electret Microphone Amplifier (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Datasheet
