U063 · M5Stack
Unit Fan is a DC motor Unit, made with an N20 DC motor, with an output shaft speed of 8800 RPM (no load). Utilizing its unidirectional rotation feature, it can be used as a power source in structures that require motion control, such as controlling wheel rotation. Features Unidirectional rotation DC 5V power supply Includes 1 x Unit Fan 1 x HY2.0-4P Grove cable (20cm) 2 x Propellers Applications Motion control Specifications Specification Parameter Product Size 32.0 x 24.0 x 12.2mm Product… (M5Stack U063)
| Part number | U063 |
|---|---|
| Manufacturer | M5Stack |
| Category | Motors & Actuators › Fans |
| Pins | 4 |
| Voltage (max) | 5 V |
Mini Fan Unit - N20 Magnetic Motor with Propellers pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | SIG1 | bidirectional | PORT.B: GPIO/analog; PORT.C: UART - see the unit's pin map |
| 2 | SIG2 | bidirectional | PORT.B: GPIO/analog; PORT.C: UART - see the unit's pin map |
| 3 | 5V | power | |
| 4 | GND | ground |
Schematic symbol and footprint
Schematic symbol
Footprint: Grove HY2.0 4-pin through-hole, 2.0 mm pitch — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
