ADA1085 · Adafruit
Adafruit product #1085 — built on ADS1115.
| Part number | ADA1085 |
|---|---|
| Manufacturer | Adafruit |
| Category | Audio › Amplifiers & Audio Modules |
| Pins | 12 |
| Resolution | 16 bit |
| Channels | 4 |
ADS1115 16-Bit ADC - 4 Channel with Programmable Gain Amplifier pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | AVDD | bidirectional | |
| 2 | AIN3 | bidirectional | |
| 3 | AIN2 | bidirectional | |
| 4 | AIN1 | bidirectional | |
| 5 | AIN0 | bidirectional | |
| 6 | AGND | ground | |
| 7 | VCC | power | |
| 8 | GND | ground | |
| 9 | SCL | bidirectional | |
| 10 | SDA | bidirectional | |
| 11 | ADDR | bidirectional | |
| 12 | ALERT | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit ADS1115 16-Bit ADC (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
