ADA3779 · Adafruit
Adafruit product #3779 — built on AS7262.
| Part number | ADA3779 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › Light & Colour |
| Pins | 14 |
| Channels | 6 |
Adafruit AS7262 6-Channel Visible Light / Color Sensor Breakout pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | GND | ground | |
| 2 | VIN | power | |
| 3 | RX/SCL | bidirectional | |
| 4 | TX/SDA | bidirectional | |
| 5 | LED | bidirectional | |
| 6 | LED | bidirectional | |
| 7 | 3.3V | power | |
| 8 | VIN | power | |
| 9 | 3.3V | power | |
| 10 | GND | ground | |
| 11 | RX/SCL | bidirectional | |
| 12 | TX/SDA | bidirectional | |
| 13 | RESET | bidirectional | |
| 14 | INT | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit AS7262 Visible Spetral Sensor (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
