ADA2342 · Adafruit
Adafruit product #2342.
| Part number | ADA2342 |
|---|---|
| Manufacturer | Adafruit |
| Category | Memory & Storage › SD & Storage Modules |
| Pins | 22 |
Adafruit Audio FX Mini Sound Board - WAV/OGG Trigger - 2MB Flash pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VIN | power | |
| 2 | GND | ground | |
| 3 | VBUS | power | |
| 4 | TX | bidirectional | |
| 5 | RX_5V | bidirectional | |
| 6 | UG | bidirectional | |
| 7 | CS | bidirectional | |
| 8 | GND | ground | |
| 9 | R_AC | bidirectional | |
| 10 | L_AC | bidirectional | |
| 11 | GND | ground | |
| 12 | RST | bidirectional | |
| 13 | GPIO0_0 | bidirectional | |
| 14 | GPIO0_1 | bidirectional | |
| 15 | GPIO0_2 | bidirectional | |
| 16 | GPIO0_3 | bidirectional | |
| 17 | GPIO0_4 | bidirectional | |
| 18 | GPIO0_5 | bidirectional | |
| 19 | GPIO0_6 | bidirectional | |
| 20 | GPIO0_7 | bidirectional | |
| 21 | ACT | bidirectional | |
| 22 | GND | ground |
Schematic symbol and footprint
Footprint: Adafruit Audio FX Mini Sound Board (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Datasheet
