ADA4470 · AdafruitActive
Adafruit product #4470 — built on MCP4728.
| Part number | ADA4470 |
|---|---|
| Manufacturer | Adafruit |
| Category | Memory & Storage › SD & Storage Modules |
| Pins | 12 |
Adafruit MCP4728 Quad DAC with EEPROM pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | GND | ground | |
| 2 | VOUTA | bidirectional | |
| 3 | VOUTB | bidirectional | |
| 4 | VOUTC | bidirectional | |
| 5 | VOUTD | bidirectional | |
| 6 | VCC | power | |
| 7 | VCC | power | |
| 8 | GND | ground | |
| 9 | SCL | bidirectional | |
| 10 | SDA | bidirectional | |
| 11 | !LDAC | bidirectional | |
| 12 | RDY | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit MCP4728 (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
