Name: Adafruit CRICKIT for micro:bit
Brand: Adafruit

Parts › Motor Drivers & Controllers › Brushed DC Motor Drivers

ADA3928 · AdafruitActive

Adafruit CRICKIT for micro:bit illustration

Adafruit product #3928.

Part number	ADA3928
Manufacturer	Adafruit
Category	Motor Drivers & Controllers › Brushed DC Motor Drivers
Pins	77

Adafruit CRICKIT for micro:bit pinout

Pin	Name	Type
1	SERVO1	bidirectional
2	5.0V	bidirectional
3	SERVO2	bidirectional
4	5.0V	bidirectional
5	DRIVEOUT1	bidirectional
6	SERVO3	bidirectional
7	5.0V	bidirectional
8	GND	ground
9	DRIVEOUT2	bidirectional
10	SERVO4	bidirectional
11	5.0V	bidirectional
12	GND	ground
13	5.0V	bidirectional
14	GND	ground
15	DRIVEOUT3	bidirectional
16	GND	ground
17	DRIVEOUT4	bidirectional
18	ANALOG1	bidirectional
19	3.3V	power
20	GND	ground
21	ANALOG2	bidirectional
22	3.3V	power
23	GND	ground
24	MOTOR_1A_OUT	bidirectional
25	ANALOG3	bidirectional
26	3.3V	power
27	GND	ground
28	MOTOR_1B_OUT	bidirectional
29	ANALOG4	bidirectional
30	3.3V	power
31	GND	ground
32	GND	ground
33	ANALOG5	bidirectional
34	3.3V	power
35	GND	ground
36	ANALOG6	bidirectional
37	3.3V	power
38	GND	ground
39	MOTOR_2A_OUT	bidirectional
40	#3	bidirectional
41	#0	bidirectional
42	#4	bidirectional
43	#5	bidirectional
44	#6	bidirectional
45	#7	bidirectional
46	#1	bidirectional
47	#8	bidirectional
48	#9	bidirectional
49	#10	bidirectional
50	#11	bidirectional
51	#12	bidirectional
52	#2	bidirectional
53	#13	bidirectional
54	#14	bidirectional
55	#15	bidirectional
56	#16	bidirectional
57	SCL	bidirectional
58	SDA	bidirectional
59	GND	ground
60	+3V	power
61	ANALOG7	bidirectional
62	3.3V	power
63	GND	ground
64	MOTOR_2B_OUT	bidirectional
65	ANALOG8	bidirectional
66	3.3V	power
67	GND	ground
68	IRQ	bidirectional
69	SPKR-	bidirectional
70	CAPTOUCH1	bidirectional
71	SPKR+	bidirectional
72	CAPTOUCH2	bidirectional
73	5.0V	bidirectional
74	NEOPIXELOUT	bidirectional
75	CAPTOUCH3	bidirectional
76	GND	ground
77	CAPTOUCH4	bidirectional
