ADA4286 · AdafruitActive
Adafruit product #4286 — built on DS3502. Interfaces: I2C.
| Part number | ADA4286 |
|---|---|
| Manufacturer | Adafruit |
| Category | User Input & Controls › Potentiometers & Sliders |
| Pins | 10 |
Adafruit DS3502 I2C Digital 10K Potentiometer Breakout pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | RL | bidirectional | |
| 2 | RW | bidirectional | |
| 3 | RH | bidirectional | |
| 4 | V+ | power | |
| 5 | VCC | power | |
| 6 | GND | ground | |
| 7 | SCL | bidirectional | |
| 8 | SDA | bidirectional | |
| 9 | A0 | bidirectional | |
| 10 | A1 | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit DS3502 (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
