Adafruit IS31FL3741 13x9 PWM RGB LED Matrix Driver

Parts › Displays & LEDs › LED Matrix & Segment

ADA5201 · Adafruit

Adafruit IS31FL3741 13x9 PWM RGB LED Matrix Driver photo
Adafruit IS31FL3741 13x9 PWM RGB LED Matrix Driver illustration

Adafruit product #5201 — built on IS31FL3741.

Part numberADA5201
ManufacturerAdafruit
CategoryDisplays & LEDs › LED Matrix & Segment
Pins7

Adafruit IS31FL3741 13x9 PWM RGB LED Matrix Driver pinout

PinNameTypeDescription
1VCCpower
2GNDground
3SCLbidirectional
4SDAbidirectional
5SHUTDOWNbidirectional
6ADDRbidirectional
7INTbidirectional

Schematic symbol and footprint

1234567
Footprint: Adafruit IS31FL3741 (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.

Where to buy

SupplierStockPriceStatus
Mouser123$14.95 (1+)View

Stock and prices from the suppliers, checked 2026-10-08; excluding tax and shipping.
