ADA6250 · AdafruitActive
Adafruit product #6250 — built on PCM5102. Interfaces: I2S.
| Part number | ADA6250 |
|---|---|
| Manufacturer | Adafruit |
| Category | Audio › Amplifiers & Audio Modules |
| Pins | 14 |
Adafruit PCM5102 I2S DAC with Line Level Output - 112dB SNR pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | DEMPH | bidirectional | |
| 2 | FILTER | bidirectional | |
| 3 | SCK_IN | bidirectional | |
| 4 | MUTE | bidirectional | |
| 5 | FORMAT | bidirectional | |
| 6 | 3.3V | power | |
| 7 | VIN | power | |
| 8 | AGND | ground | |
| 9 | WORDSEL_IN | bidirectional | |
| 10 | DATA_IN | bidirectional | |
| 11 | BITCLK_IN | bidirectional | |
| 12 | OUTL | bidirectional | |
| 13 | AGND | ground | |
| 14 | OUTR | bidirectional |
