Name: Adafruit Radio FeatherWing - RFM69HCW 900MHz
Brand: Adafruit

ADA3229 · AdafruitActive

Adafruit product #3229 — built on RFM69HCW.

Part number	ADA3229
Manufacturer	Adafruit
Category	Communication & Wireless › Sub-GHz & RF Transceivers
Pins	60
Frequency	900 MHz

Adafruit Radio FeatherWing - RFM69HCW 900MHz pinout

Pin	Name	Type
1	VBAT	power
2	EN	bidirectional
3	USB	power
4	H	bidirectional
5	G	bidirectional
6	A	bidirectional
7	B	bidirectional
8	C	bidirectional
9	D	bidirectional
10	E	bidirectional
11	SCL	bidirectional
12	SDA	bidirectional
13	VBAT	power
14	EN	bidirectional
15	USB	power
16	H	bidirectional
17	G	bidirectional
18	DIO1	bidirectional
19	A	bidirectional
20	B	bidirectional
21	C	bidirectional
22	D	bidirectional
23	E	bidirectional
24	DIO2	bidirectional
25	IRQ	bidirectional
26	DIO3	bidirectional
27	CS	bidirectional
28	DIO4	bidirectional
29	RF_RST	bidirectional
30	F	bidirectional
31	RX	bidirectional
32	TX	bidirectional
33	SCL	bidirectional
34	SDA	bidirectional
35	DIO5	bidirectional
36	RST	bidirectional
37	3.3V	power
38	AREF	bidirectional
39	GND	ground
40	I	bidirectional
41	J	bidirectional
42	K	bidirectional
43	L	bidirectional
44	M	bidirectional
45	RST	bidirectional
46	3.3V	power
47	AREF	bidirectional
48	GND	ground
49	I	bidirectional
50	J	bidirectional
51	K	bidirectional
52	L	bidirectional
53	M	bidirectional
54	F	bidirectional
55	SCK	bidirectional
56	MOSI	bidirectional
57	MISO	bidirectional
58	RX	bidirectional
59	TX	bidirectional
60	NC	bidirectional
