ADA5972 · AdafruitActive
Adafruit product #5972. Interfaces: USB.
| Part number | ADA5972 |
|---|---|
| Manufacturer | Adafruit |
| Category | User Input & Controls › Buttons & Keypads |
| Pins | 8 |
Adafruit Switchable USB Type A to C Breakout Board pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | G_M | bidirectional | |
| 2 | P_M | bidirectional | |
| 3 | N_M | bidirectional | |
| 4 | V_M | bidirectional | |
| 5 | G_F | bidirectional | |
| 6 | P_F | bidirectional | |
| 7 | N_F | bidirectional | |
| 8 | V_F | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit Switchable USB Type A to C Breakout Board (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
