ADA6525 · Adafruit
Adafruit product #6525 — built on TCS3448.
| Part number | ADA6525 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › Light & Colour |
| Pins | 6 |
| Channels | 14 |
Adafruit TCS3448 14-Channel Light / Color Sensor Breakout pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VCC | power | |
| 2 | GND | ground | |
| 3 | SCL | bidirectional | |
| 4 | SDA | bidirectional | |
| 5 | GPIO | bidirectional | |
| 6 | INT | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit TCS3448 14-Channel Light Color Sensor Breakout (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
