ADA746 · Adafruit
Adafruit product #746.
| Part number | ADA746 |
|---|---|
| Manufacturer | Adafruit |
| Category | Communication & Wireless › GNSS / GPS |
| Pins | 9 |
| Frequency | 10 Hz |
| Channels | 66 |
Adafruit Ultimate GPS Breakout - 66 channel w/10 Hz updates pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | 3.3V | power | |
| 2 | ENABLE | bidirectional | |
| 3 | VBACKUP | bidirectional | |
| 4 | FIX | bidirectional | |
| 5 | TX | bidirectional | |
| 6 | RX | bidirectional | |
| 7 | GND | ground | |
| 8 | VIN | power | |
| 9 | 1PPS | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit Ultimate GPS v3 (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
