ADA3133 · AdafruitActive
Adafruit product #3133.
| Part number | ADA3133 |
|---|---|
| Manufacturer | Adafruit |
| Category | Communication & Wireless › GNSS / GPS |
| Pins | 49 |
Adafruit Ultimate GPS FeatherWing pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VBAT | power | |
| 2 | EN | bidirectional | |
| 3 | USB | power | |
| 4 | N | bidirectional | |
| 5 | M | bidirectional | |
| 6 | L | bidirectional | |
| 7 | K | bidirectional | |
| 8 | J | bidirectional | |
| 9 | I | bidirectional | |
| 10 | H | bidirectional | |
| 11 | SCL | bidirectional | |
| 12 | SDA | bidirectional | |
| 13 | EN | bidirectional | |
| 14 | USB | power | |
| 15 | N | bidirectional | |
| 16 | M | bidirectional | |
| 17 | L | bidirectional | |
| 18 | GPS_RESET | bidirectional | |
| 19 | FIX | bidirectional | |
| 20 | 1PPS | bidirectional | |
| 21 | ENABLE | bidirectional | |
| 22 | GPS_TX | bidirectional | |
| 23 | GPS_RX | bidirectional | |
| 24 | RST | bidirectional | |
| 25 | 3V | power | |
| 26 | AREF | bidirectional | |
| 27 | GND | ground | |
| 28 | A | bidirectional | |
| 29 | B | bidirectional | |
| 30 | C | bidirectional | |
| 31 | D | bidirectional | |
| 32 | E | bidirectional | |
| 33 | F | bidirectional | |
| 34 | RST | bidirectional | |
| 35 | 3V | power | |
| 36 | AREF | bidirectional | |
| 37 | GND | ground | |
| 38 | A | bidirectional | |
| 39 | B | bidirectional | |
| 40 | C | bidirectional | |
| 41 | D | bidirectional | |
| 42 | E | bidirectional | |
| 43 | F | bidirectional | |
| 44 | SCK | bidirectional | |
| 45 | MOSI | bidirectional | |
| 46 | MISO | bidirectional | |
| 47 | RX | bidirectional | |
| 48 | TX | bidirectional | |
| 49 | G | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit GPS FeatherWing (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Datasheet
Where to buy
Stock and prices from the suppliers, checked 2026-10-08; excluding tax and shipping.
