ADA5810 · AdafruitActive
Adafruit product #5810 — built on VCNL4020. Interfaces: I2C.
| Part number | ADA5810 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › Light & Colour |
| Pins | 7 |
Adafruit VCNL4020 Proximity and Light Sensor - STEMMA QT / Qwiic pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | CATH | bidirectional | |
| 2 | VCC | power | |
| 3 | 3.3V | power | |
| 4 | GND | ground | |
| 5 | SCL | bidirectional | |
| 6 | SDA | bidirectional | |
| 7 | INT | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit VCNL4020 Proximity and Light Sensor (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
