DFR0029-B · DFRobot
Digital push button features LED indicator, wide voltage range, durable design, and easy plug-and-play functionality, ideal for interactive projects. (DFRobot DFR0029-B; also DFR0029-G, DFR0029-R, DFR0029-W, DFR0029-Y)
| Part number | DFR0029-B |
|---|---|
| Manufacturer | DFRobot |
| Category | User Input & Controls › Buttons & Keypads |
| Pins | 3 |
Gravity: Digital Push Button pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | SIG | bidirectional | Digital or analog signal |
| 2 | VCC | power | |
| 3 | GND | ground |
Schematic symbol and footprint
Footprint: JST PH 2.0 mm 3-pin through-hole (Gravity PH2.0-3P) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
