ADA4440 · Adafruit
Adafruit product #4440. Interfaces: I2C.
| Part number | ADA4440 |
|---|---|
| Manufacturer | Adafruit |
| Category | Displays & LEDs › OLED |
| Pins | 6 |
Monochrome 0.91" 128x32 I2C OLED Display - STEMMA QT / Qwiic pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | SDA | bidirectional | |
| 2 | SCL | bidirectional | |
| 3 | RESET | bidirectional | |
| 4 | GND | ground | |
| 5 | 3.3V | power | |
| 6 | VCC | power |
Schematic symbol and footprint
Footprint: Adafruit OLED Monochrome 0.91in I2C with STEMMA QT (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Datasheet
