ADA1362 · Adafruit
Adafruit product #1362 — built on 5-PAD, AT42QT1070.
| Part number | ADA1362 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › Touch & Gesture |
| Pins | 12 |
Standalone 5-Pad Capacitive Touch Sensor Breakout - AT42QT1070 pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | CAP4 | bidirectional | |
| 2 | OUT4 | bidirectional | |
| 3 | CAP3 | bidirectional | |
| 4 | OUT3 | bidirectional | |
| 5 | CAP2 | bidirectional | |
| 6 | OUT2 | bidirectional | |
| 7 | CAP1 | bidirectional | |
| 8 | OUT1 | bidirectional | |
| 9 | CAP0 | bidirectional | |
| 10 | OUT0 | bidirectional | |
| 11 | GND | ground | |
| 12 | VDD | power |
Schematic symbol and footprint
Footprint: Adafruit Standalone 5-Pad Capacitive Touch Sensor Breakout - AT42QT1070 (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
