ADA1374 · Adafruit
Adafruit product #1374.
| Part number | ADA1374 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › Touch & Gesture |
| Pins | 4 |
Standalone Momentary Capacitive Touch Sensor Breakout pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | GND | ground | |
| 2 | OUT | bidirectional | |
| 3 | VDD | power | |
| 4 | LEDA | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit AT42QT1010 Standalone Momentary Capacitive Touch Sensor (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
