ADA3200 · AdafruitActive
Adafruit product #3200.
| Part number | ADA3200 |
|---|---|
| Manufacturer | Adafruit |
| Category | Development Boards › Other ARM & RISC-V Boards |
| Pins | 64 |
Teensy 3.x Feather Adapter pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VBAT | power | |
| 2 | VBUS | power | |
| 3 | 5 | bidirectional | |
| 4 | 6 | bidirectional | |
| 5 | 9 | bidirectional | |
| 6 | 10 | bidirectional | |
| 7 | 4 | bidirectional | |
| 8 | 3 | bidirectional | |
| 9 | 8 | bidirectional | |
| 10 | SCL | bidirectional | |
| 11 | SDA | bidirectional | |
| 12 | VBUS | power | |
| 13 | AGND | ground | |
| 14 | +3V3 | power | |
| 15 | 23/A9 | bidirectional | |
| 16 | 22/A8 | bidirectional | |
| 17 | A7 | bidirectional | |
| 18 | A6 | bidirectional | |
| 19 | SCL | bidirectional | |
| 20 | SDA | bidirectional | |
| 21 | A3 | bidirectional | |
| 22 | A2 | bidirectional | |
| 23 | A1 | bidirectional | |
| 24 | A0 | bidirectional | |
| 25 | SCK | bidirectional | |
| 26 | VUSB | bidirectional | |
| 27 | AREF | bidirectional | |
| 28 | A10 | bidirectional | |
| 29 | A11 | bidirectional | |
| 30 | A14 | bidirectional | |
| 31 | BOOT | bidirectional | |
| 32 | GND | ground | |
| 33 | +3V3 | power | |
| 34 | VBAT | power | |
| 35 | GND | ground | |
| 36 | RX | bidirectional | |
| 37 | TX | bidirectional | |
| 38 | 2 | bidirectional | |
| 39 | 3 | bidirectional | |
| 40 | 4 | bidirectional | |
| 41 | 5 | bidirectional | |
| 42 | 6 | bidirectional | |
| 43 | 7 | bidirectional | |
| 44 | 8 | bidirectional | |
| 45 | 9 | bidirectional | |
| 46 | 10 | bidirectional | |
| 47 | MOSI | bidirectional | |
| 48 | MISO | bidirectional | |
| 49 | RST/BOOT | bidirectional | |
| 50 | +3V3 | power | |
| 51 | AREF | bidirectional | |
| 52 | GND | ground | |
| 53 | A14 | bidirectional | |
| 54 | A1 | bidirectional | |
| 55 | A3 | bidirectional | |
| 56 | A2 | bidirectional | |
| 57 | A0 | bidirectional | |
| 58 | A6 | bidirectional | |
| 59 | SCK | bidirectional | |
| 60 | MOSI | bidirectional | |
| 61 | MISO | bidirectional | |
| 62 | RX | bidirectional | |
| 63 | TX | bidirectional | |
| 64 | GND | ground |
Schematic symbol and footprint
Footprint: Feather Teensy 3 Adapter (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Datasheet
Where to buy
| Supplier | Stock | Price | Status | |
|---|---|---|---|---|
| DigiKey | 2 | $6.95 (1+) | Active | View |
Stock and prices from the suppliers, checked 2026-10-08; excluding tax and shipping.
