ADA2090 · Adafruit
Adafruit product #2090.
| Part number | ADA2090 |
|---|---|
| Manufacturer | Adafruit |
| Category | Displays & LEDs › TFT LCD |
| Pins | 40 |
2.8" TFT LCD with Cap Touch Breakout Board w/MicroSD Socket pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | GND | ground | |
| 2 | VIN | power | |
| 3 | CS | bidirectional | |
| 4 | C/D_CLK | bidirectional | |
| 5 | D/C_WR | bidirectional | |
| 6 | RD | bidirectional | |
| 7 | RST | bidirectional | |
| 8 | LITE | bidirectional | |
| 9 | IRQ | bidirectional | |
| 10 | SCL | bidirectional | |
| 11 | SDA | bidirectional | |
| 12 | GND | ground | |
| 13 | D0 | bidirectional | |
| 14 | D1 | bidirectional | |
| 15 | D2 | bidirectional | |
| 16 | D3 | bidirectional | |
| 17 | D4 | bidirectional | |
| 18 | D5 | bidirectional | |
| 19 | D6 | bidirectional | |
| 20 | D7 | bidirectional | |
| 21 | GND | ground | |
| 22 | VIN | power | |
| 23 | 3.3V | power | |
| 24 | C/D_CLK | bidirectional | |
| 25 | MISO | bidirectional | |
| 26 | MOSI | bidirectional | |
| 27 | CS | bidirectional | |
| 28 | D/C_WR | bidirectional | |
| 29 | RST | bidirectional | |
| 30 | LITE | bidirectional | |
| 31 | GND | ground | |
| 32 | IRQ | bidirectional | |
| 33 | SDA | bidirectional | |
| 34 | SCL | bidirectional | |
| 35 | IM3 | bidirectional | |
| 36 | IM2 | bidirectional | |
| 37 | IM1 | bidirectional | |
| 38 | IM0 | bidirectional | |
| 39 | SD_CS | bidirectional | |
| 40 | CARDDET | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit 2.8 inch Captouch TFT (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Datasheet
