ADA3533 · Adafruit
Adafruit product #3533.
| Part number | ADA3533 |
|---|---|
| Manufacturer | Adafruit |
| Category | Displays & LEDs › TFT LCD |
| Pins | 11 |
Adafruit 0.96" 160x80 Color TFT Display w/ MicroSD Card Breakout pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VIN | power | |
| 2 | 3.3V | power | |
| 3 | GND | ground | |
| 4 | SCK | bidirectional | |
| 5 | MISO | bidirectional | |
| 6 | MOSI | bidirectional | |
| 7 | TFTCS | bidirectional | |
| 8 | TFTRST | bidirectional | |
| 9 | DC | bidirectional | |
| 10 | SDCS | bidirectional | |
| 11 | BACKLIGHT | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit Mini TFT Display - 0.96in 160x80 (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Datasheet
