Name: Adafruit Assembled Data Logging shield for Arduino
Brand: Adafruit

ADA1141 · AdafruitActive

Adafruit product #1141.

Part number	ADA1141
Manufacturer	Adafruit
Category	Interface & Expansion › Expansion Boards & Shields
Pins	69

Adafruit Assembled Data Logging shield for Arduino pinout

Pin	Name	Type
1	SCL	bidirectional
2	SDA	bidirectional
3	AREF	bidirectional
4	GND	ground
5	SCK	bidirectional
6	MISO	bidirectional
7	MOSI	bidirectional
8	SD_CS	bidirectional
9	D9	bidirectional
10	D8	bidirectional
11	D7	bidirectional
12	D6	bidirectional
13	D5	bidirectional
14	D4	bidirectional
15	D3	bidirectional
16	D2	bidirectional
17	D1	bidirectional
18	D0	bidirectional
19	AREF	bidirectional
20	GND	ground
21	SCK	bidirectional
22	MISO	bidirectional
23	MOSI	bidirectional
24	SD_CS	bidirectional
25	D9	bidirectional
26	D8	bidirectional
27	D7	bidirectional
28	D6	bidirectional
29	D5	bidirectional
30	D4	bidirectional
31	D3	bidirectional
32	D2	bidirectional
33	D1	bidirectional
34	D0	bidirectional
35	SD_CS	bidirectional
36	LED2	bidirectional
37	LED1	bidirectional
38	SD_CD	bidirectional
39	SD_WP	bidirectional
40	SQW	bidirectional
41	+3V3	power
42	SDA	bidirectional
43	SCL	bidirectional
44	RESET	bidirectional
45	3.3V	power
46	+5V	power
47	GND	ground
48	GND	ground
49	VIN	power
50	A0	bidirectional
51	A1	bidirectional
52	A2	bidirectional
53	A3	bidirectional
54	SDA	bidirectional
55	SCL	bidirectional
56	NC	bidirectional
57	IOREF	bidirectional
58	RESET	bidirectional
59	3.3V	power
60	+5V	power
61	GND	ground
62	GND	ground
63	VIN	power
64	A0	bidirectional
65	A1	bidirectional
66	A2	bidirectional
67	A3	bidirectional
68	SDA	bidirectional
69	SCL	bidirectional
