ADA4741 · Adafruit
Adafruit product #4741.
| Part number | ADA4741 |
|---|---|
| Manufacturer | Adafruit |
| Category | Displays & LEDs › OLED |
| Pins | 8 |
Adafruit Grayscale 1.5" 128x128 OLED Graphic Display pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | SDA | bidirectional | |
| 2 | SCL | bidirectional | |
| 3 | DC/SA0_5.0V | bidirectional | |
| 4 | RST_5.0V | bidirectional | |
| 5 | CS_5.0V | bidirectional | |
| 6 | 3.3V | power | |
| 7 | VCC | power | |
| 8 | GND | ground |
Schematic symbol and footprint
Footprint: Adafruit Grayscale 1.5" 128x128 OLED Graphic Display - STEMMA QT / Qwiic (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Where to buy
| Supplier | Stock | Price | Status | |
|---|---|---|---|---|
| Mouser | 227 | $22.50 (1+) | View |
Stock and prices from the suppliers, checked 2026-10-08; excluding tax and shipping.
