ADA4535 · Adafruit
Adafruit product #4535 — built on HTS221.
| Part number | ADA4535 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › Temperature & Humidity |
| Pins | 7 |
Adafruit HTS221 - Temperature & Humidity Sensor Breakout Board pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VCC | power | |
| 2 | 3.3V | power | |
| 3 | GND | ground | |
| 4 | SCL | bidirectional | |
| 5 | SDA | bidirectional | |
| 6 | DRDY | bidirectional | |
| 7 | CS | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit HTS221 (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Datasheet
