ADA2857 · Adafruit
Adafruit product #2857 — built on SHT31-D.
| Part number | ADA2857 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › Temperature & Humidity |
| Pins | 7 |
Adafruit Sensirion SHT31-D pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VCC | power | |
| 2 | GND | ground | |
| 3 | SCL | bidirectional | |
| 4 | SDA | bidirectional | |
| 5 | ADDR | bidirectional | |
| 6 | !RESET | bidirectional | |
| 7 | ALERT | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit SHT31-D (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
