ADA4712 · AdafruitActive
Adafruit product #4712 — built on LC709203F.
| Part number | ADA4712 |
|---|---|
| Manufacturer | Adafruit |
| Category | Power › Batteries & Holders |
| Pins | 6 |
Adafruit LC709203F LiPoly / LiIon Fuel Gauge and Battery Monitor pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VCC | power | |
| 2 | GND | ground | |
| 3 | SCL | bidirectional | |
| 4 | SDA | bidirectional | |
| 5 | INT | bidirectional | |
| 6 | THERM | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit LC709203F Fuel Gauge and Battery Monitor (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
