ADA5580 · AdafruitActive
Adafruit product #5580 — built on MAX17048.
| Part number | ADA5580 |
|---|---|
| Manufacturer | Adafruit |
| Category | Power › Batteries & Holders |
| Pins | 8 |
Adafruit MAX17048 LiPoly / LiIon Fuel Gauge and Battery Monitor pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VBAT | power | |
| 2 | GND | ground | |
| 3 | VCC | power | |
| 4 | GND | ground | |
| 5 | SCL | bidirectional | |
| 6 | SDA | bidirectional | |
| 7 | INT | bidirectional | |
| 8 | QSTART | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit MAX17048 LiPoly / LiIon Fuel Gauge and Battery Monitor (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
