ADA4413 · AdafruitActive
Adafruit product #4413 — built on LSM303AGR. Interfaces: I2C.
| Part number | ADA4413 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › IMU, Accelerometers & Gyros |
| Pins | 10 |
Adafruit LSM303AGR Accelerometer Magnetometer - STEMMA QT Qwiic pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | CS_MAG | bidirectional | |
| 2 | CS_ACCEL | bidirectional | |
| 3 | INT1A_3V | bidirectional | |
| 4 | INT2A_3V | bidirectional | |
| 5 | VCC | power | |
| 6 | 3.3V | power | |
| 7 | GND | ground | |
| 8 | SCL | bidirectional | |
| 9 | SDA | bidirectional | |
| 10 | INTM_3V | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit LSM303AGR (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Datasheet
Where to buy
Stock and prices from the suppliers, checked 2026-10-08; excluding tax and shipping.
