ADA6066 · AdafruitActive
Adafruit product #6066.
| Part number | ADA6066 |
|---|---|
| Manufacturer | Adafruit |
| Category | Displays & LEDs › LED Drivers & Controllers |
| Pins | 8 |
Adafruit Pixel Shifter - For Addressable LEDs pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | GND | ground | |
| 2 | GND | ground | |
| 3 | VIN | power | |
| 4 | DAT_5V | bidirectional | |
| 5 | DAT_3V | bidirectional | |
| 6 | !DAT_5V | bidirectional | |
| 7 | CLK_3V | bidirectional | |
| 8 | CLK_5V | bidirectional |
Schematic symbol and footprint
Schematic symbol
Footprint: Adafruit Pixel Shifter (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
