ADA6280 · AdafruitActive
Adafruit product #6280 — built on TPS65131.
| Part number | ADA6280 |
|---|---|
| Manufacturer | Adafruit |
| Category | Power › Voltage Regulators & DC-DC |
| Pins | 7 |
Adafruit TPS65131 Split Power Supply Boost Converter pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | +12V | bidirectional | |
| 2 | GND | ground | |
| 3 | VDD | power | |
| 4 | GND | ground | |
| 5 | ENABLE | bidirectional | |
| 6 | GND | ground | |
| 7 | -12V | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit TPS65131 Split Power Supply Boost Converter (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Where to buy
| Supplier | Stock | Price | Status | |
|---|---|---|---|---|
| Mouser | 15 | $6.95 (1+) | New at Mouser | View |
Stock and prices from the suppliers, checked 2026-10-08; excluding tax and shipping.
