Name: PowerBoost 1000 Basic - 5V USB Boost @ 1000mA from 1.8V+
Brand: Adafruit

ADA2030 · Adafruit

Adafruit product #2030. Interfaces: USB.

Part number	ADA2030
Manufacturer	Adafruit
Category	Power › Voltage Regulators & DC-DC
Pins	10
Voltage (max)	5 V
Current	1 A

PowerBoost 1000 Basic - 5V USB Boost @ 1000mA from 1.8V+ pinout

Pin	Name	Type
1	VBAT	power
2	GND	ground
3	ENABLE	bidirectional
4	LBO	bidirectional
5	GND	ground
6	5.0V	bidirectional
7	VBAT	power
8	GND	ground
9	GND	ground
10	5.0V	bidirectional

Schematic symbol and footprint

Footprint: PowerBoost 1000 Basic (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
