ADA512 · Adafruit
Adafruit product #512 — built on 2-AXIS. Interfaces: Analog.
| Part number | ADA512 |
|---|---|
| Manufacturer | Adafruit |
| Category | User Input & Controls › Joysticks & Gamepads |
| Pins | 5 |
Analog 2-axis Thumb Joystick with Select Button + Breakout Board pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VCC | power | |
| 2 | XOUT | bidirectional | |
| 3 | YOUT | bidirectional | |
| 4 | SWITCH | bidirectional | |
| 5 | GND | ground |
Schematic symbol and footprint
Footprint: Adafruit Analog 2-Axis Joystick (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Datasheet
