ADA3246 · Adafruit
Adafruit product #3246. Interfaces: Analog.
| Part number | ADA3246 |
|---|---|
| Manufacturer | Adafruit |
| Category | User Input & Controls › Joysticks & Gamepads |
| Pins | 8 |
Analog Mini Thumbstick Breakout Board pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VCC | power | |
| 2 | YOUT | bidirectional | |
| 3 | XOUT | bidirectional | |
| 4 | GND | ground | |
| 5 | VCC | power | |
| 6 | YOUT | bidirectional | |
| 7 | XOUT | bidirectional | |
| 8 | GND | ground |
Schematic symbol and footprint
Footprint: Adafruit Mini Analog Thumbstick (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
