Name: DC Motor + Stepper FeatherWing Add-on For All Feather Boards
Brand: Adafruit

ADA2927 · AdafruitActive

Adafruit product #2927.

Part number	ADA2927
Manufacturer	Adafruit
Category	Motor Drivers & Controllers › Stepper Motor Drivers
Pins	66

DC Motor + Stepper FeatherWing Add-on For All Feather Boards pinout

Pin	Name	Type
1	VBAT	power
2	EN	bidirectional
3	USB	power
4	N	bidirectional
5	M	bidirectional
6	L	bidirectional
7	K	bidirectional
8	J	bidirectional
9	I	bidirectional
10	H	bidirectional
11	SCL	bidirectional
12	SDA	bidirectional
13	GND	ground
14	VMOTOR	bidirectional
15	VBAT	power
16	EN	bidirectional
17	USB	power
18	N	bidirectional
19	M	bidirectional
20	L	bidirectional
21	K	bidirectional
22	J	bidirectional
23	I	bidirectional
24	H	bidirectional
25	SCL	bidirectional
26	SDA	bidirectional
27	M1A	bidirectional
28	M4A	bidirectional
29	M1B	bidirectional
30	M4B	bidirectional
31	M2B	bidirectional
32	M3B	bidirectional
33	M2A	bidirectional
34	M3A	bidirectional
35	RESET	bidirectional
36	+3.3V	power
37	AREF	bidirectional
38	GND	ground
39	A	bidirectional
40	B	bidirectional
41	C	bidirectional
42	D	bidirectional
43	E	bidirectional
44	F	bidirectional
45	SCK	bidirectional
46	MOSI	bidirectional
47	MISO	bidirectional
48	RX	bidirectional
49	TX	bidirectional
50	G	bidirectional
51	RESET	bidirectional
52	+3.3V	power
53	AREF	bidirectional
54	GND	ground
55	A	bidirectional
56	B	bidirectional
57	C	bidirectional
58	D	bidirectional
59	E	bidirectional
60	F	bidirectional
61	SCK	bidirectional
62	MOSI	bidirectional
63	MISO	bidirectional
64	RX	bidirectional
65	TX	bidirectional
66	G	bidirectional
