ADA292 · Adafruit
Adafruit product #292. Interfaces: I2C, SPI.
| Part number | ADA292 |
|---|---|
| Manufacturer | Adafruit |
| Category | Displays & LEDs › Character LCD |
| Pins | 21 |
i2c / SPI character LCD backpack - STEMMA QT / Qwiic pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | LEDK | bidirectional | |
| 2 | VCC | power | |
| 3 | DB7 | bidirectional | |
| 4 | DB6 | bidirectional | |
| 5 | DB5 | bidirectional | |
| 6 | DB4 | bidirectional | |
| 7 | DB3 | bidirectional | |
| 8 | DB2 | bidirectional | |
| 9 | DB1 | bidirectional | |
| 10 | DB0 | bidirectional | |
| 11 | E | bidirectional | |
| 12 | GND | ground | |
| 13 | RS | bidirectional | |
| 14 | CONTRAST | bidirectional | |
| 15 | VCC | power | |
| 16 | GND | ground | |
| 17 | LATCH | bidirectional | |
| 18 | DATA | bidirectional | |
| 19 | CLOCK | bidirectional | |
| 20 | VCC | power | |
| 21 | GND | ground |
Schematic symbol and footprint
Schematic symbol
Footprint: Adafruit I2C+SPI LCD Backpack (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
