Name: OLED Breakout Board - 16-bit Color 1.27" w/microSD holder
Brand: Adafruit

Parts › Displays & LEDs › OLED

ADA1673 · Adafruit

OLED Breakout Board - 16-bit Color 1.27" w/microSD holder photo

OLED Breakout Board - 16-bit Color 1.27" w/microSD holder illustration

Adafruit product #1673.

Part number	ADA1673
Manufacturer	Adafruit
Category	Displays & LEDs › OLED
Pins	11
Resolution	16 bit

OLED Breakout Board - 16-bit Color 1.27" w/microSD holder pinout

Pin	Name	Type
1	MOSI	bidirectional
2	CLK	bidirectional
3	DC	bidirectional
4	RESET	bidirectional
5	OLEDCS	bidirectional
6	SDCS	bidirectional
7	MISO	bidirectional
8	SD_CD	bidirectional
9	3.3V	power
10	VIN	power
11	GND	ground

Schematic symbol and footprint

Footprint: 1.27 inch 16-bit Color OLED w microSD holder (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
