ADA1431 · Adafruit
Adafruit product #1431.
| Part number | ADA1431 |
|---|---|
| Manufacturer | Adafruit |
| Category | Displays & LEDs › OLED |
| Pins | 11 |
| Resolution | 16 bit |
OLED Breakout Board - 16-bit Color 1.5" w/microSD holder pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | MOSI | bidirectional | |
| 2 | SCK | bidirectional | |
| 3 | DC | bidirectional | |
| 4 | RESET | bidirectional | |
| 5 | OLED_CS | bidirectional | |
| 6 | SD_CS | bidirectional | |
| 7 | SD_MISO | bidirectional | |
| 8 | SD_CD | bidirectional | |
| 9 | 3.3V | power | |
| 10 | VIN | power | |
| 11 | GND | ground |
Schematic symbol and footprint
Footprint: OLED Color 1.5 inch 128x128 w microSD (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
