Name: Proto-Screwshield (Wingshield) R3 Kit for Arduino
Brand: Adafruit

Parts › Interface & Expansion › Expansion Boards & Shields

ADA196 · Adafruit

Proto-Screwshield (Wingshield) R3 Kit for Arduino photo

Proto-Screwshield (Wingshield) R3 Kit for Arduino illustration

Adafruit product #196.

Part number	ADA196
Manufacturer	Adafruit
Category	Interface & Expansion › Expansion Boards & Shields
Pins	111

Proto-Screwshield (Wingshield) R3 Kit for Arduino pinout

Pin	Name	Type
1	SCL	bidirectional
2	SDA	bidirectional
3	AREF	bidirectional
4	GND	ground
5	D13	bidirectional
6	D12	bidirectional
7	D11	bidirectional
8	D10	bidirectional
9	D9	bidirectional
10	D8	bidirectional
11	D7	bidirectional
12	D6	bidirectional
13	D5	bidirectional
14	D4	bidirectional
15	D3	bidirectional
16	D2	bidirectional
17	D1	bidirectional
18	D0	bidirectional
19	SCL	bidirectional
20	SDA	bidirectional
21	AREF	bidirectional
22	GND	ground
23	D13	bidirectional
24	D12	bidirectional
25	D11	bidirectional
26	D10	bidirectional
27	D9	bidirectional
28	D8	bidirectional
29	D7	bidirectional
30	D6	bidirectional
31	D5	bidirectional
32	D4	bidirectional
33	D3	bidirectional
34	D2	bidirectional
35	D1	bidirectional
36	D0	bidirectional
37	SCL	bidirectional
38	SDA	bidirectional
39	AREF	bidirectional
40	GND	ground
41	D13	bidirectional
42	D12	bidirectional
43	D11	bidirectional
44	D10	bidirectional
45	D9	bidirectional
46	D8	bidirectional
47	D7	bidirectional
48	D6	bidirectional
49	D5	bidirectional
50	D4	bidirectional
51	D3	bidirectional
52	D2	bidirectional
53	D1	bidirectional
54	D0	bidirectional
55	LED	bidirectional
56	MISO	bidirectional
57	5V_ICSP	bidirectional
58	SCK	bidirectional
59	MOSI	bidirectional
60	RESET	bidirectional
61	GND	ground
62	NC	bidirectional
63	IOREF	bidirectional
64	RST	bidirectional
65	3V	power
66	+5V	power
67	GND	ground
68	GND	ground
69	VIN	power
70	A0	bidirectional
71	A1	bidirectional
72	A2	bidirectional
73	A3	bidirectional
74	A4	bidirectional
75	A5	bidirectional
76	W	bidirectional
77	X	bidirectional
78	Y	bidirectional
79	Z	bidirectional
80	NC	bidirectional
81	IOREF	bidirectional
82	RST	bidirectional
83	3V	power
84	+5V	power
85	GND	ground
86	GND	ground
87	VIN	power
88	A0	bidirectional
89	A1	bidirectional
90	A2	bidirectional
91	A3	bidirectional
92	A4	bidirectional
93	A5	bidirectional
94	W	bidirectional
95	X	bidirectional
96	Y	bidirectional
97	Z	bidirectional
98	RST	bidirectional
99	3V	power
100	+5V	power
101	GND	ground
102	GND	ground
103	VIN	power
104	A0	bidirectional
105	A1	bidirectional
106	A2	bidirectional
107	A3	bidirectional
108	A4	bidirectional
109	A5	bidirectional
110	GND	ground
111	GND	ground
