102010610 · Seeed Studio

XIAO MG24 Sense is an ultra-low-power wireless development board based on Silicon Labs' EFR32MG24 SoC, featuring a high-performance 78MHz ARM Cortex®-M33 core. It‘s Matter ® native over Thread ® and Bluetooth® Low Energy 5.3 , all supported by the Arduino ® Core . With 4MB Flash onboard, 19 GPIOs, LED, and charging circuit onboard , it boasts extremely low operating current and ultra-low-power modes, making it an ideal choice for IoT applications, especially battery-powered projects utilizing Matter ® protocols. Additionally, the onboard analog microphone and six-axis IMU sensors make XIAO… (Seeed SKU 102010610; also 102010691)
| Part number | 102010610 |
|---|---|
| Manufacturer | Seeed Studio |
| Category | Development Boards › Other ARM & RISC-V Boards |
| Pins | 14 |
| Frequency | 78 MHz |
Seeed Studio XIAO MG24 Sense pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | D0/A0 | bidirectional | |
| 2 | D1/A1 | bidirectional | |
| 3 | D2/A2 | bidirectional | |
| 4 | D3/A3 | bidirectional | |
| 5 | D4/SDA | bidirectional | |
| 6 | D5/SCL | bidirectional | |
| 7 | D6/TX | bidirectional | |
| 8 | D7/RX | bidirectional | |
| 9 | D8/SCK | bidirectional | |
| 10 | D9/MISO | bidirectional | |
| 11 | D10/MOSI | bidirectional | |
| 12 | 3V3 | power | |
| 13 | GND | ground | |
| 14 | 5V | power |
Schematic symbol and footprint
Schematic symbol
Footprint: Seeed Studio XIAO (2 x 7, 15.24 mm rows) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
