GPS-22660 · SparkFunActive
The SparkFun ZED-F9R GPS-RTK Breakout is a high-precision Automotive Dead Reckoning board with equally impressive configuration options. (SparkFun GPS-22660)
| Part number | GPS-22660 |
|---|---|
| Manufacturer | SparkFun |
| Category | Communication & Wireless › GNSS / GPS |
| Pins | 4 |
SparkFun GPS-RTK Dead Reckoning Breakout - ZED-F9R, SMA (Qwiic) pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | GND | ground | |
| 2 | 3V3 | power | |
| 3 | SDA | bidirectional | |
| 4 | SCL | input |
Schematic symbol and footprint
Schematic symbol
Footprint: JST-SH 4-pin SMD right-angle (SM04B-SRSS-TB) - Qwiic / STEMMA QT — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
