LCD-22495 · SparkFunActive
This Qwiic-enabled 0.66-inch blue-on-black OLED screen can display graphics and sensor diagnostics without a serial monitor, complex soldering, or difficult hardware integration. (SparkFun LCD-22495)
| Part number | LCD-22495 |
|---|---|
| Manufacturer | SparkFun |
| Category | Displays & LEDs › OLED |
| Pins | 4 |
SparkFun Micro OLED Breakout (Qwiic) pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | D0/SCL/SCK | bidirectional | |
| 2 | D1/SDA/PICO | bidirectional | |
| 3 | VDD | power | |
| 4 | GND | ground |
Schematic symbol and footprint
Footprint: SparkFun Qwiic Micro OLED Breakout (Top View) (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Where to buy
Stock and prices from the suppliers, checked 2026-10-08; excluding tax and shipping.
